Vintage Austin Register Limited Spares List, April 2023
Parts are of new manufacture, and Items are priced individually, unless shown otherwise. Post and packaging is additionally charged at cost, as is any fee incurred by the payment method
| AUSTIN 16/6 PARTS, UP TO JANUARY 1934 | Part no. | Qty req | Price |
| Starting handle dog | EC2 | 1 | £55 |
| Starting handle shaft | EF19 | 1 | £50 |
| Starting handle spring– needs shortening | EF21 | 1 | £6 |
| Starting handle shaft bush | EF22 | 1 | £14 |
| Timing chain metal tensioner | EC26-29 | 1 | £40 |
| Fibre chain tensioner | 1 | £35 | |
| Timing chain – 86 link only (shorten to 82 link as req’d) | EC23 | 1 | £220 |
| Dynamo rubber coupling | EL6 | 1 | £27.50 |
| Water pump casting – machined | EL30 | 1 | £370 |
| Water pump gland nut(LH=20/6) | EL23 | 1 | £22 |
| Water pump spindle | EL19 | 1 | £110 |
| Cylinder head gasket | ED18 | 1 | £110 |
| Inlet manifold gasket set | EH5+6 | 2 + 2 | £12.50 |
| Cylinder head studs ( BSF/BSW) | ED6 | 24 | £3 |
| Sump bolts W deep head £35 set (1/4”BSW not for tin sump–post 1929) | EA97 | 28 | £1.75 |
| Main bearing lock washer | EA108 | 8 | 1.70 |
| Little end lock washer | EE23 | 6 | 0.80 |
| Valves – exhaust quality | EE1,EE2 | 12 | £27 |
| Valve guides | EE9 | 12 | £25 |
| Valve springs | EE3 | 12 | £6 |
| Valve spring cups, collet type | EE4 | 12 | £3.30 |
| Valve collets | EE5 | 24 | £1.90 |
| Tappet screws (ground face heads) (16/6 short) | EE7 | 12 | £3.90 |
| Tappet nuts | EE8 | 12 | £2.75 |
| Core plug – 1” diameter press fit | £1.25 | ||
| Core plug – 1.25” diameter press fit | £1.65 | ||
| Core plug – 1.3125” diameter press fit | £1.65 | ||
| Core plug – 1.5” diameter press fit | £1.65 | ||
| Core plug – 1.575” diameter press fit | £2.10 | ||
| Oil filters- complete | EM25 | 1 | £175 |
| Replacement elements (2 types) | £12 | ||
| Circlip or 2-pin pliers | £17 | ||
| Spare “O” rings(2 types), circlips | £1.10ea | ||
| Spare unions | £3.30 | ||
| Clutch linings and rivets | EP26/EP42 | 2 | £40set |
| Clutch springs | EP22 | 15 | £40set |
| Clutch fingers – sets of 3 | EP18 | 3 | £45set |
| Vibration puller – LOAN ONLY | £16.50 | ||
| Dipstick top | EA47 | 1 | £20 |
| Starter motor Bendix spring, LH/RH | 1 | £36 | |
| Exhaust manifold gasket set | EH2+3 | 4 + 1 | £48 |
| Exhaust manifold brass nuts 5/16”BSF (8 steel on inlet) | ED12 | 11 | £1.50 |
| Exhaust silencer box | EJ10/28 | 1 | £110 |
| Exhaust tailpipe | EJ19/37 | 1 | £88 |
| Exhaust downpipe | EJ27 | 1 | £105 |
